1

LCD monitor with Clinical D-image

C240P4QPYEW/75

LCD monitor with Clinical D-image

C240P4QPYEW/75

Clinical Review Display

This Philips display is ideal for everyday clinical care environment. D-image preset gives you consistent DICOM grayscale medical images. Its medical grade power supply ensures basic safety. See all benefits

LCD monitor with Clinical D-image

Clinical Review Display

This Philips display is ideal for everyday clinical care environment. D-image preset gives you consistent DICOM grayscale medical images. Its medical grade power supply ensures basic safety. See all benefits

Clinical Review Display

This Philips display is ideal for everyday clinical care environment. D-image preset gives you consistent DICOM grayscale medical images. Its medical grade power supply ensures basic safety. See all benefits

LCD monitor with Clinical D-image

Clinical Review Display

This Philips display is ideal for everyday clinical care environment. D-image preset gives you consistent DICOM grayscale medical images. Its medical grade power supply ensures basic safety. See all benefits

Register

Subscribe to our newsletter

Clinical Review Display

with Brilliant Images

  • Clinical review display
  • 24.1" (61 cm)
  • 1920 x 1200 (2 MP)
Clinical D-image preset for DICOM part 14 Grayscale images

Clinical D-image preset for DICOM part 14 Grayscale images

Monitors must show medical images consistently with high quality to achieve reliable interpretations. The rendering of medical Grayscale images on standard monitors is mostly inconsistent at best, making them unsuitable for usage in a clinical environment. Philips clinical review displays with clinical D-image preset are factory calibrated to give DICOM part 14 compatible Grayscale standard display performance. By using high quality LCD panels with LED technology, Philips offers you consistent and reliable performance at an affordable price point. Further info on http://medical.nema.org/

IPS technology for full colors and wide viewing angles

IPS technology for full colors and wide viewing angles

IPS displays use an advanced technology which gives you extra wide viewing angles of 178/178 degree, making it possible to view the display from almost any angle - even in 90 degree Pivot mode! Unlike standard TN panels, IPS displays gives you remarkably crisp images with vivid colors, making it ideal not only for Photos, movies and web browsing, but also for professional applications which demand color accuracy and consistent brightness at all times.

PowerSensor saves up to 80% energy costs

PowerSensor saves up to 80% energy costs

PowerSensor is a built-in 'people sensor' that transmits and receives harmless infrared signals to determine if user is present and automatically reduces monitor brightness when user steps away from the desk, cutting energy costs by up to 80 percent and prolonging monitor life

SmartErgoBase enables people-friendly ergonomic adjustments

SmartErgoBase enables people-friendly ergonomic adjustments

The SmartErgoBase is a monitor base that delivers ergonomic display comfort and provides cable management. The base's people-friendly height, swivel, tilt and rotation angle adjustments position the monitor for maximum comfort that can ease the physical strains of a long workday; cable management reduces cable clutter and keeps the workspace neat and professional.

Low bezel-to-table height for maximum reading comfort

Low bezel-to-table height for maximum reading comfort

The Philips monitor, thanks to its advanced SmartErgoBase, can be lowered down almost to desk level for a comfortable viewing angle. Low bezel-to-table height is the perfect solution if you use bifocals, trifocals or progressive lens glasses for your computing work. Additionally, it allows for users with greatly different heights to use the monitor in their preferred angle and height settings, helping them reduce fatigue and strain.

SmartImage Clinic for common display settings

SmartImage is an exclusive, leading edge Philips technology that analyzes the content displayed on your screen, and based on different applications/images displayed on a monitor, SmartImage optimizes display content by dynamically adjusting brightness, contrast, color and sharpness in real time.

Medical grade power supply ensures safety with low emission

Basic safety, essential performance and reliability are essential requirements in a professional clinical environment. Unlike standard displays, Philips clinical review displays employ special medical grade power supplies in order to meet these requirements. It complies with EN/IEC 60601-1 standard ensuring basic safety and essential performance. Additionally it also complies with EN/IEC 60601-1-2 collateral standard for medical grade electromagnetic tests and compatibility. Many countries, hospitals and clinics mandate compliance to these standards as a requirement.

DisplayPort offers audio and video over a single, long cable

DisplayPort is a digital link from PC to Monitor without any conversion. With higher capabilities than DVI standard, it is fully capable to support up to 15meter cables and 10.8 Gbps/sec data transfer. With this high performance and zero latency, you get the fastest imaging and refresh rates - making DisplayPort the best choice for not only general office or home use, but also for the demanding gaming and movies, video editing and more. It also keeps interoperability in mind via use of various adapters.

USB Hub with 4 ports for easy connections

USB Hub allows user to conveniently connect their plug and play multimedia devices such as USB memory devices, camera, portable HDD, Web camera, PDA, Printer and many other devices which has USB connection available. The conveniently located USB 2.0 Hub on the monitor allows USB 2.0 signals to pass thru to the computer. Note that many devices like cameras and HDD may need to be powered On independently, as they have higher power requirements than the monitor USB Hub can provide.

Built-in stereo speakers for multimedia

A pair of high quality stereo speakers built into a display device. It can be visible front firing, or invisible down firing, top firing, rear firing, etc depending on model and design.

Technical Specifications

  • Picture/Display

    LCD panel type
    IPS technology
    Backlight type
    W-LED system
    Panel Size
    24 inch / 61 cm
    Effective viewing area
    518.4 (H) x 324 (V)
    Aspect ratio
    16:10
    Optimum resolution
    1920 x 1200 @ 60Hz
    Response time (typical)
    14  ms
    Brightness
    300  cd/m²
    Contrast ratio (typical)
    1,000:1
    Pixel pitch
    0.270 x 0.270 mm
    Viewing angle
    • 178º (H) / 178º (V)
    • @ C/R > 10
    Display colors
    16.7 M
    Scanning Frequency
    24 - 94 kHz (H) / 48 - 85 Hz (V)
    sRGB
    Yes
    Picture enhancement
    SmartImage Clinic
    DICOM
    • Clinical D-image
    • DICOM part-14
    DICOM calibrated brightness
    265  cd/m²
  • Connectivity

    Signal Input
    • DisplayPort 1.2
    • DVI-D (digital, HDCP)
    • VGA (Analog )
    USB
    USB 2.0 x 4
    Sync Input
    • Sync on Green
    • Separate Sync
    Audio (In/Out)
    • PC audio-in
    • Headphone out
    Built-in speakers
    2Wx2
  • Convenience

    User convenience
    • SmartImage Clinic
    • PowerSensor
    • Menu
    • Power On/Off
    • 4:3 / Wide
    Control software
    SmartControl
    OSD Languages
    • English
    • French
    • German
    • Italian
    • Portuguese
    • Russian
    • Simplified Chinese
    • Spanish
    • Brazil Portuguese
    • Czech
    • Dutch
    • Finnish
    • Greek
    • Hungarian
    • Japanese
    • Korean
    • Polish
    • Swedish
    • Traditional Chinese
    • Turkish
    • Ukranian
    Other convenience
    • Kensington lock
    • VESA mount (100x100mm)
    Plug & Play Compatibility
    • DDC/CI
    • Mac OS X
    • sRGB
    • Windows 8.1 / 8 / 7
  • Stand

    Height adjustment
    130  mm
    Pivot
    90 degree
    Swivel
    -65/65  degree
    Tilt
    -5/20  degree
  • Power

    On mode
    31.4 W (typ.)
    Standby mode
    0.5 W (typ.)
    Off mode
    Zero watts with Zero switch
    Power LED indicator
    • Operation - White
    • Standby mode- White (blinking)
    External power supply
    100-240VAC, 50-60Hz (Medical cert.: IEC60601-1 / EN60601-1)
  • Dimensions

    Product with stand(max height)
    555 x 550 x 244  mm
    Product without stand (mm)
    555 x 388 x 65  mm
    Packaging in mm (WxHxD)
    632 x 457 x 286  mm
  • Weight

    Product with stand (kg)
    6.97  kg
    Product without stand (kg)
    4.64  kg
    Product with packaging (kg)
    9.80  kg
  • Operating conditions

    Temperature range (operation)
    0°C to 40°C  °C
    Temperature range (storage)
    -20°C to 60°C  °C
    Relative humidity
    20%-80  %
    Altitude
    Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
    MTBF
    30,000  hour(s)
  • Sustainability

    Environmental and energy
    • PowerSensor
    • RoHS
    • WEEE
    Recyclable packaging material
    100  %
    Specific Substances
    • PVC / BFR free housing
    • Mercury free
    • Lead free
  • Compliance and standards

    EMC
    • IEC/EN60601-1-2
    • CE Mark
    Safety
    • IEC/EN60601-1
    • CE Mark
    Ergonomic/Others
    • JIS Z2801
    • TUV/GS
    • TUV Ergo
    • ISO 13485 certified
    • CCC
    • CECP
    • RCM
    • UL/cUL
    • TCO certified
  • Cabinet

    Front bezel
    White
    Rear cover
    White
    Foot
    White
    Finish
    Texture
