SureSigns VM1
Vital signs monitor
SureSigns VM1
Vital signs monitor
Philips SureSigns VM1 is a cost-effective, easy to use, and easy to support patient monitor. Designed for adult, pediatric, and neonatal patients, it offers SpO₂, heart rate with options for CO₂, and key respiratory measurement parameters.
Features
Microstream CO₂ for intubated and non-intubated patients
Add the Microstream CO₂ option to take capnography measurements on intubated and non-intubated patients in a variety of care settings.
Philips SpO₂ technology supports diverse sensors
Philips SpO₂ technology is compatible with a wide variety of adult, pediatric, and neonatal sensors from Philips, Nellcor* and Masimo*.
Bright, color backlit screen shows key vital signs
Large color-coded numerics clearly show key vital signs, and are easily visible in a variety of lighting conditions. Confirmation of export records is easily seen in green.
Specifications
- SureSigns VM1 monitor
- monitor width
- 26.0/10.2 cm/"
- monitor height
- 9.0/3.5 cm/"
- monitor depth
- 23/9.1 cm/"
- monitor weight
- including optional CO₂ module and recorder: 1.82/4.0 kg/lbs
- screen
- WQVGA TFT-AM LCD display: 10.9 cm/4.3"
- SpO₂
- Measurement Range: 0 to 100 Accuracy depends on sensor. Heart rate measurement range: 30 to 300 bpm. Heart rate accuracy ± 2% or ± 1 bpm whichever is greater. Complies with EN ISO 9919 standard
- CO₂ (optional)
- Microstream technology. Measurement range: 0 to 150 mmHg.Accuracy: 0 - 38 mmHg, ± 2 mmHg. 39 - 99 mmHg, ± 5% of reading (+ 0.08% for every 1 mmHg above 38 mmHg) 100 - 150 ± mmHg, ± 5% of reading (+ 0.08% for every 1 mmHg above 38 mmHg)
- Battery
- Internal lithium ion 10.8 to 11.1 V. Operating time: 6 hours with continuous SpO₂ measurements every 4 hours
- Data output
- HL7 format via Ethernet port. USB port. Optional serial interface adapter
- Patient type
- Adult/Pediatric/Neonatal
- Display modes
- large numeric display numeric and waveform display tabular trend display graphical trend display
- Respiration measurement
- 0-150
- Respiration accuracy
- ±1rpm in the range of 0-70rpm ±2rpm in the range of 71-120rpm ±3rpm in the range of 121-150rpm
- Recorder Type (optional)
- Paper width: 58mm Speed: 6.25mm, 12.5mm, 25mm, and 50mm/sec; user selectable
Disclaimer
* Not available in all markets
